The DEHENG DH-C pillow cover making machine converts roll material into disposable pillow covers with automatic feeding, welding, cutting, folding and counting. PLC control and a touchscreen allow operators to set production parameters for the required product.
The machine supports PE film, spunlace nonwoven and spunbond PP nonwoven. Typical nonwoven fabric weight is 20–40 gsm. Material and finished pillow-cover dimensions can be configured to suit the intended application.
With the appropriate settings and configuration, the production line can also make disposable towels, medical wrap sheets and disposable baby blankets. Share a sample or drawing so DEHENG can confirm the required process.
Raw material feeding → edge wrapping → longitudinal welding → transverse welding → cutting → folding → finished product conveying.
Ultrasonic welding forms the seams without sewing thread. Cutting lengths and folding parameters are adjusted through the PLC control system. Operating speed is 10–20 m/min, depending on the material, product size and configuration.
Send the material specification, finished pillow-cover size and folding or packing requirements to DEHENG. We will confirm the configuration and installation requirements for your project. Call 0086-18066372911.
Explore our disposable linen production solutions for related equipment.
Start with the required pillow cover rather than selecting equipment only by a product name. Provide the finished length and width, opening design and a drawing of the required fold. Include a physical sample or photographs if the opening and seams are difficult to describe.
The pillow cover making machine configuration should be confirmed against the material and finished design. List the intended PE film, spunlace or spunbond PP specification, including thickness or gsm as appropriate. If you plan several cover designs, submit a sample or drawing for each one and identify the main production product.
The confirmed operating speed is 10–20 meters per minute. This is a material-processing speed, not a fixed number of finished pillow covers per minute. Product dimensions and the selected process affect the finished-piece output, so provide the required product size when discussing capacity.
Automatic counting is standard. Stacking and online packing are optional and should be requested in the quotation. Describe how you want to collect or package the product so the selected configuration addresses the intended production process.
The listed materials are PE film, spunlace nonwoven and spunbond PP nonwoven. Send the specification of the material you intend to use so DEHENG can confirm the configuration for the required cover design.
No. Automatic counting is standard, while stacking and online packing are optional. Specify these handling functions when requesting the machine configuration and quotation.
No. This page describes pillow cover production. For larger bedding products, review the disposable duvet cover making machine and provide a separate product drawing.
Send the pillow cover sample or drawing, finished dimensions, opening and folding design, material specification, required output and optional handling needs.
Email sales@de-heng.com or dehengmachinery@gmail.com to discuss your pillow cover making machine requirements.
| Item | Specification |
|---|---|
| Model | DH-C |
| Product | Disposable pillow covers / pillow cases |
| Materials | PE film, spunlace nonwoven, spunbond PP nonwoven |
| Typical nonwoven weight | 20–40 gsm |
| Operating speed | 10–20 m/min, depending on product and material |
| Control | PLC with touchscreen |
| Finished dimensions | Customized to requirements |
| Automatic counting | Standard |
| Stacking | Optional |
| Online packing | Optional |
| Power supply | 380V / 220V, customizable according to customer requirements |
Total power and machine layout are confirmed for the selected configuration.
The machine processes PE film, spunlace nonwoven and spunbond PP nonwoven. Typical nonwoven weight is 20–40 gsm. Speed is 10–20 m/min, depending on material and product size. Automatic counting is standard; stacking and online packing are optional. Finished dimensions and the final configuration are confirmed from your sample or drawing.
