The DEHENG DH-GY5 mask blank making machine forms 1–5 material layers into flat mask bodies using ultrasonic welding. Production speed is 100 pcs/min. Finished mask blank length is 125–180 mm and width is 80–110 mm. This machine produces mask bodies only; ear-loop welding requires separate equipment. Finished mask blanks are discharged by conveyor.
Touchscreen control supports speed settings, production counting and preset-count alarm or stopping. Mask dimensions, material-layer structure and nose-strip requirements are confirmed for the selected product design and tooling.
Explore the separate inner ear-loop welding machine or outer ear-loop welding machine and confirm the required production arrangement.
Email: sales@de-heng.com or dehengmachinery@gmail.com.
The mask blank making machine handles the body-forming stage of a flat-mask production process. Its output is a mask body rather than a finished mask with ear loops. This distinction matters when planning equipment, staffing and the next production stage. Confirm the separate ear-loop welding arrangement before ordering the line.
The DH-GY5 is specified at 100 mask bodies per minute. When planning the complete process, compare that output with the capacity and handling requirements of the downstream welding equipment. Include your intended finished-mask design in the inquiry so the equipment selection can be reviewed as a complete production arrangement.
The machine supports one to five material layers. Provide the specification of each layer, including material composition and weight, rather than only the total number of layers. Also send the intended nose-strip specification and pleat design. These details help DEHENG confirm the tooling and product settings for your sample.
The confirmed mask-body length range is 125–180 mm, and the width range is 80–110 mm. Dimensions should be stated for the mask body shown in your drawing. If you need several sizes, list each size and ask which adjustments or tooling are required for the selected configuration.
No. The DH-GY5 produces mask bodies only. Ear-loop welding requires separate equipment. Specify whether your product needs inner or outer ear-loop attachment when discussing the downstream stage.
The confirmed production speed for this mask blank making machine is 100 pcs/min. Include the required output of the complete production process in your inquiry, together with your collection and packing requirements.
A finished sample or clear drawing is the starting point. Add the length, width, pleat design, layer-by-layer material specifications, nose-strip details and intended ear-loop arrangement. Photos of the front and back of the required mask are useful when explaining the product design.
The power supply can be configured for 380V or 220V according to customer requirements. State the electrical supply available at your installation site so the selected machine configuration can be confirmed.
Provide a separate drawing for each mask size, with the intended production quantity for each design. This helps clarify tooling requirements, changeover needs and the priorities for your machine configuration.
| Model | DH-GY5 |
| power | 2 kW; power supply 380V / 220V, customizable according to customer requirements |
| Speed | 100 pcs/min |
| Machine weight | 800 kg |
| Machine size | 2100×600×1200mm（L*W*H） |
| Feeding rack size | 1700×600×1400mm（L*W*H） |
| Conveyor size | 2800×350×910mm（L*W*H） |
| Material layers | 1–5 layers |
| Finished mask blank length | 125–180 mm |
| Finished mask blank width | 80–110 mm |
| Production scope | Mask bodies only; ear-loop welding requires separate equipment |
